Swirl Diffuser 24 Fixed Blades
SKU AD-SDFA-24
Feature Description
- Power coated white
- The face is made of galvanized steel 0.8mm thick
- M6x100mm or M8x160 central fixing screw are available
- The angle of the blades is 38 degree
Accesories (Optional)
- 10x10mm black gasket
- Plenum box with bracket
- Silicone plug for screw head
- Plastic plug for screw head
Quantity
Size Chart
| Code | ØA | B-B | H | BLADES |
|---|---|---|---|---|
|
EAV 80 |
Ø356 | 595x595 | 41 | 22 |
| EAV 100 | Ø497 | 595x595 | 41 | 22 |
| Code | ØA | B-B | H | Blades |
|---|---|---|---|---|
| SDFB-24 595/350D | Ø348 | 595x595 | 36 | 24 |
| SDFB-24 595/500D | Ø500 | 595x595 | 36 | 24 |
| SDFB-24 595/535D | Ø533 | 595x595 | 36 | 24 |
